HP AlphaServer ES45 system
Delivers large-system speed, power, and performance at a midrange server price. Designed to handle the toughest business, technical and scientific applications with stunning speed.
The ideal choice for crucial resource-intensive applications such as Oracle, SAP, and SAS in e-business, telecom and high performance technical computing.
Powered by up to four 1.25 GHz Alpha processors with increased memory bandwidth and now including hot-plug-ready PCI expansion slots.
Reliability features include hot-swap RAID storage, advanced clustering support, and redundant hot-swap power and cooling system.
| General | |
| Type | Server |
| Recommended Use | Corporate business |
| Server Scalability | 4-way |
| Front Accessible Bays Qty | 4 |
| Processor | |
| Type | Alpha 21264D 1.25 GHz |
| Installed Qty | 1 |
| Max Supported Qty | 4 |
| Upgradability | Upgradable |
| Cache Memory | |
| Type | L2 Cache |
| Installed Size | 16 MB |
| Cache Per Processor | 16 MB |
| RAM | |
| Installed Size | 4 GB / 32 GB (max) |
| Upgrade Rule | 4 modules at a time |
| Storage | |
| Floppy Drive | 3.5" 1.44 MB floppy |
| Hard Drive | None. |
| Optical Storage | |
| Type | DVD-ROM |
| Read Speed | 16x |
| Monitor | |
| Monitor Type | None. |
| Expansion / Connectivity | |
| Expansion Bays Total (Free) | 3 ( 2 ) x front accessible - 5.25" x 1/2H 1 ( 0 ) x front accessible - 3.5" x 1/3H 2 ( 2 ) x drive cage |
| Expansion Slots Total (Free) | 6 ( 6 ) x PCI 64 / 66 MHz 4 ( 4 ) x PCI 64 / 33 MHz 4 ( 3 ) x processor 32 memory |
| Interfaces | 2 x serial - RS-232C - 9 pin D-Sub (DB-9) 1 x parallel - IEEE 1284 (EPP/ECP) - 25 pin D-Sub (DB-25) 1 x keyboard - generic - 6 pin mini-DIN (PS/2 style) 1 x mouse - generic - 6 pin mini-DIN (PS/2 style) 1 x management - 6 PIN MMJ |
| Miscellaneous | |
| Compliant Standards | TUV, C-Tick, BSMI CNS 13438 Class A, EN 60950, EN 61000-3-2, EN55022, UL 1950, VCCI Class A ITE, IEC 60950, EN 61000-3-3, EN55024, CSA 22.2 No. 950, UL 60950 |
| Power | |
| Device Type | Power supply - hot-plug |
| Power Redundancy | Optional |
| Installed Qty | 1 |
| Max Supported Qty | 3 |
| Voltage Required | AC 230V ( 50/60 Hz ) |
| Power Provided | 1080 Watt |
| Operating System / Software | |
| OS Provided | Compaq Tru64 UNIX |
| Manufacturer Warranty | |
| Service & Support | 1 year warranty |
| Service & Support Details | Limited warranty - 1 year - on-site - response time: next business day |
| Environmental Parameters | |
| Min Operating Temperature | 10 °C |
| Max Operating Temperature | 35 °C |
| Humidity Range Operating | 20 - 80% |
